うんぱん馬車 ( )| データテーブル | イメージ | 製造元。セクション # | ストック | 価格 | はかる | Package / Case | Packaging | Series | Product Status | Output Configuration | Output Type | Number of Regulators | Voltage - Input ( Max ) | Voltage - Output ( Min / Fixed ) | Voltage - Output ( Max ) | Voltage Dropout(Max) | Current - Output | Current - Quiescent ( Iq ) | Current - Supply ( Max ) | PSRR | Control Features | Protection Features | Operating Temperature | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
データテーブル |
|
LT3009ESC8-1.5IC REG LINEAR 1.5V 20MA SC70 |
3335 | 0.00 |
カートに追加今すぐ検索 |
8-VFSOP (0.049, 1.25mm Width) | Tube | - | Obsolete | Positive | Fixed | 1 | 20V | 1.5V | - | 0.45V @ 20mA | 20mA | 6 µA | 1 mA | 67dB (120Hz) | Enable | Over Current, Over Temperature, Reverse Polarity | -40°C ~ 125°C | Surface Mount |
|
データテーブル |
|
LT3009ESC8-1.8IC REG LINEAR 1.8V 20MA SC70 |
3043 | 0.00 |
カートに追加今すぐ検索 |
8-VFSOP (0.049, 1.25mm Width) | Tube | - | Obsolete | Positive | Fixed | 1 | 20V | 1.8V | - | 0.45V @ 20mA | 20mA | 6 µA | 1 mA | 66dB (120Hz) | Enable | Over Current, Over Temperature, Reverse Polarity | -40°C ~ 125°C | Surface Mount |
|
データテーブル |
|
LT3009ESC8-2.5IC REG LINEAR 2.5V 20MA SC70 |
3210 | 0.00 |
カートに追加今すぐ検索 |
8-VFSOP (0.049, 1.25mm Width) | Tube | - | Obsolete | Positive | Fixed | 1 | 20V | 2.5V | - | 0.45V @ 20mA | 20mA | 6 µA | 1 mA | 63dB (120Hz) | Enable | Over Current, Over Temperature, Reverse Polarity | -40°C ~ 125°C | Surface Mount |
|
データテーブル |
|
LT3009ESC8-3.3IC REG LINEAR 3.3V 20MA SC70 |
2922 | 0.00 |
カートに追加今すぐ検索 |
8-VFSOP (0.049, 1.25mm Width) | Tube | - | Obsolete | Positive | Fixed | 1 | 20V | 3.3V | - | 0.45V @ 20mA | 20mA | 6 µA | 1 mA | 61dB (120Hz) | Enable | Over Current, Over Temperature, Reverse Polarity | -40°C ~ 125°C | Surface Mount |
|
データテーブル |
|
LT3009ESC8-5IC REG LINEAR 5V 20MA SC70 |
2980 | 0.00 |
カートに追加今すぐ検索 |
8-VFSOP (0.049, 1.25mm Width) | Tube | - | Obsolete | Positive | Fixed | 1 | 20V | 5V | - | 0.45V @ 20mA | 20mA | 6 µA | 1 mA | 56dB (120Hz) | Enable | Over Current, Over Temperature, Reverse Polarity | -40°C ~ 125°C | Surface Mount |
|
データテーブル |
|
LT3029EDEIC REG LIN POS ADJ 500MA 16DFN |
2133 | 0.00 |
カートに追加今すぐ検索 |
16-WFDFN Exposed Pad | Tube | - | Obsolete | Positive | Adjustable | 2 | 20V | 1.215V | 19.5V | 0.46V @ 500mA, 0.46V @ 500mA | 500mA, 500mA | - | - | 67dB (120Hz) | Enable | Over Current, Over Temperature, Reverse Polarity | -40°C ~ 125°C | Surface Mount |
|
データテーブル |
|
LT3029HDEIC REG LIN POS ADJ 500MA 16DFN |
3725 | 0.00 |
カートに追加今すぐ検索 |
16-WFDFN Exposed Pad | Tube | - | Obsolete | Positive | Adjustable | 2 | 20V | 1.215V | 19.5V | 0.46V @ 500mA, 0.46V @ 500mA | 500mA, 500mA | - | - | 67dB (120Hz) | Enable | Over Current, Over Temperature, Reverse Polarity | -40°C ~ 150°C | Surface Mount |
|
データテーブル |
|
LT3029IDEIC REG LIN POS ADJ 500MA 16DFN |
2226 | 0.00 |
カートに追加今すぐ検索 |
16-WFDFN Exposed Pad | Tube | - | Obsolete | Positive | Adjustable | 2 | 20V | 1.215V | 19.5V | 0.46V @ 500mA, 0.46V @ 500mA | 500mA, 500mA | - | - | 67dB (120Hz) | Enable | Over Current, Over Temperature, Reverse Polarity | -40°C ~ 125°C | Surface Mount |
| |
|
LT3050EDDBIC REG LIN POS ADJ 100MA 12DFN |
3955 | 0.00 |
カートに追加今すぐ検索 |
12-WFDFN Exposed Pad | Tube | - | Obsolete | Positive | Adjustable | 1 | 45V | 0.6V | 44.5V | 0.55V @ 100mA | 100mA | 90 µA | 5.2 mA | 85dB (120Hz) | Current Limit, Enable, Soft Start | Over Current, Over Temperature, Reverse Polarity | -40°C ~ 125°C | Surface Mount |
| |
|
LT3050EDDB-3.3IC REG LINEAR 3.3V 100MA 12DFN |
3095 | 0.00 |
カートに追加今すぐ検索 |
12-WFDFN Exposed Pad | Tube | - | Obsolete | Positive | Fixed | 1 | 45V | 3.3V | - | 0.55V @ 100mA | 100mA | 90 µA | 5.2 mA | 70dB (120Hz) | Current Limit, Enable, Soft Start | Over Current, Over Temperature, Reverse Polarity | -40°C ~ 125°C | Surface Mount |
| |
|
LT3050EDDB-5IC REG LINEAR 5V 100MA 12DFN |
3612 | 0.00 |
カートに追加今すぐ検索 |
12-WFDFN Exposed Pad | Tube | - | Obsolete | Positive | Fixed | 1 | 45V | 5V | - | 0.55V @ 100mA | 100mA | 90 µA | 5.2 mA | 66dB (120Hz) | Current Limit, Enable, Soft Start | Over Current, Over Temperature, Reverse Polarity | -40°C ~ 125°C | Surface Mount |
| |
|
LT3050IDDBIC REG LIN POS ADJ 100MA 12DFN |
2777 | 0.00 |
カートに追加今すぐ検索 |
12-WFDFN Exposed Pad | Tube | - | Obsolete | Positive | Adjustable | 1 | 45V | 0.6V | 44.5V | 0.55V @ 100mA | 100mA | 90 µA | 5.2 mA | 85dB (120Hz) | Current Limit, Enable, Soft Start | Over Current, Over Temperature, Reverse Polarity | -40°C ~ 125°C | Surface Mount |
| |
|
LT3050IDDB-3.3IC REG LINEAR 3.3V 100MA 12DFN |
3046 | 0.00 |
カートに追加今すぐ検索 |
12-WFDFN Exposed Pad | Tube | - | Obsolete | Positive | Fixed | 1 | 45V | 3.3V | - | 0.55V @ 100mA | 100mA | 90 µA | 5.2 mA | 70dB (120Hz) | Current Limit, Enable, Soft Start | Over Current, Over Temperature, Reverse Polarity | -40°C ~ 125°C | Surface Mount |
| |
|
LT3050IDDB-5IC REG LINEAR 5V 100MA 12DFN |
2898 | 0.00 |
カートに追加今すぐ検索 |
12-WFDFN Exposed Pad | Tube | - | Obsolete | Positive | Fixed | 1 | 45V | 5V | - | 0.55V @ 100mA | 100mA | 90 µA | 5.2 mA | 66dB (120Hz) | Current Limit, Enable, Soft Start | Over Current, Over Temperature, Reverse Polarity | -40°C ~ 125°C | Surface Mount |
| |
|
LT3055EDEIC REG LIN POS ADJ 500MA 16DFN |
3354 | 0.00 |
カートに追加今すぐ検索 |
16-WFDFN Exposed Pad | Tube | - | Obsolete | Positive | Adjustable | 1 | 45V | 0.6V | 40V | 0.59V @ 500mA | 500mA | 130 µA | 25 mA | 85dB (120Hz) | Current Limit, Enable, Power Good, Soft Start | Over Current, Over Temperature, Reverse Polarity | -40°C ~ 125°C | Surface Mount |
| |
|
LT3055EDE-3.3IC REG LINEAR 3.3V 500MA 16DFN |
2077 | 0.00 |
カートに追加今すぐ検索 |
16-WFDFN Exposed Pad | Tube | - | Obsolete | Positive | Fixed | 1 | 45V | 3.3V | - | 0.59V @ 500mA | 500mA | 130 µA | 25 mA | 70dB (120Hz) | Current Limit, Enable, Power Good, Soft Start | Over Current, Over Temperature, Reverse Polarity | -40°C ~ 125°C | Surface Mount |
| |
|
LT3055EDE-5IC REG LINEAR 5V 500MA 16DFN |
2320 | 0.00 |
カートに追加今すぐ検索 |
16-WFDFN Exposed Pad | Tube | - | Obsolete | Positive | Fixed | 1 | 45V | 5V | - | 0.59V @ 500mA | 500mA | 130 µA | 25 mA | 66dB (120Hz) | Current Limit, Enable, Power Good, Soft Start | Over Current, Over Temperature, Reverse Polarity | -40°C ~ 125°C | Surface Mount |
| |
|
LT3055IDEIC REG LIN POS ADJ 500MA 16DFN |
3371 | 0.00 |
カートに追加今すぐ検索 |
16-WFDFN Exposed Pad | Tube | - | Obsolete | Positive | Adjustable | 1 | 45V | 0.6V | 40V | 0.59V @ 500mA | 500mA | 130 µA | 25 mA | 85dB (120Hz) | Current Limit, Enable, Power Good, Soft Start | Over Current, Over Temperature, Reverse Polarity | -40°C ~ 125°C | Surface Mount |
| |
|
LT3055IDE-3.3IC REG LINEAR 3.3V 500MA 16DFN |
3893 | 0.00 |
カートに追加今すぐ検索 |
16-WFDFN Exposed Pad | Tube | - | Obsolete | Positive | Fixed | 1 | 45V | 3.3V | - | 0.59V @ 500mA | 500mA | 130 µA | 25 mA | 70dB (120Hz) | Current Limit, Enable, Power Good, Soft Start | Over Current, Over Temperature, Reverse Polarity | -40°C ~ 125°C | Surface Mount |
| |
|
LT3055IDE-5IC REG LINEAR 5V 500MA 16DFN |
3352 | 0.00 |
カートに追加今すぐ検索 |
16-WFDFN Exposed Pad | Tube | - | Obsolete | Positive | Fixed | 1 | 45V | 5V | - | 0.59V @ 500mA | 500mA | 130 µA | 25 mA | 66dB (120Hz) | Current Limit, Enable, Power Good, Soft Start | Over Current, Over Temperature, Reverse Polarity | -40°C ~ 125°C | Surface Mount |
